Cone Point Set Screw

Hello everyone, I'm a manager at Zeyao Fastener Factory. We have 19 years of experience in fastener R&D and manufacturing, specializing in providing high-quality screw solutions to customers worldwide. Today, I will introduce the Cone Point Set Screw in detail.

The Cone Point Set Screw is a fastener that secures components to shafts, holes, or other parts without the need for a nut. Its unique tapered tip design allows the screw to be accurately positioned during tightening and penetrates thin material surfaces for a secure connection.

The tapered tip design is suitable for components requiring long-term fixation and infrequent disassembly, maintaining a tight fit under vibration or stress conditions, preventing loosening and displacement.

Raw Material

Cold Forging

Threading

Auto Lathe

Auto Lathe

Table Lathe

CNC Lathe

Quality Checking

Inspection

Packing

Application Scenarios

1. Mechanical Manufacturing

Cone point set screws are widely used in mechanical manufacturing to secure rotating components such as gears, pulleys, and bearing housings.

Securing Gears and Pulleys: The cone-shaped tip can embed into the surface of a gear or pulley shaft, ensuring the screw remains tight even under vibration and high-speed rotation, maintaining precise transmission.

Securing Bearing Housings: The screw provides reliable grip, preventing the bearing housing from shifting or rotating during operation, ensuring equipment stability.

2. Precision Instruments

In optical, electronic, and laboratory instruments, cone point set screws are used for precise positioning and securing of small components.

Optical Equipment: For components like lens assemblies, laser modules, or optical measurement devices, cone point screws can fix parts onto optical axes or frames, preventing minor shifts that could affect optical alignment.

Electronic Instruments: Used to secure PCB supports, sensors, or electronic modules, ensuring components remain stable despite vibration or temperature fluctuations.

Laboratory Equipment: Laboratory instruments require high repeatability; cone point screws maintain precise positioning even after multiple assemblies and disassemblies.

3. Automotive and Construction Machinery

Cone point set screws are applied in automotive and construction machinery for critical components that must withstand vibration and shock.

Engine Components: Used to secure camshafts, gears, and drive wheels, ensuring parts remain firmly in place under high-speed operation.

Chassis Connectors: Such as suspension or steering components, cone point screws provide anti-loosening locking, ensuring vehicle safety.

Hydraulic Systems: Secures valves, pumps, and other critical parts, preventing leaks or system failures caused by vibration.

4. Packaging and Automation Equipment

In automated production lines, packaging machines, and conveyor systems, cone point screws are used to secure shafts, guides, and rollers.

Securing Conveyor Rollers: The screws ensure rollers are tightly coupled to shafts, reducing slippage or misalignment and ensuring stable material transport.

Securing Drive Shafts: The cone tip provides strong grip, keeping gears or couplings from loosening during high-frequency operation.

Securing Guide Components: In packaging lines or automation equipment, guides require precise alignment; cone point screws ensure long-term stability.

5. Other Industrial Applications

Cone point set screws are also suitable for long-term securing of industrial components, particularly in high-load or high-vibration environments.

Motors, Pumps, and Valves: Secures shafts, impellers, or valve spindles, ensuring components remain stable at high speeds or pressures.

Precision Machinery: In robotic arms, CNC equipment, and automated machinery, cone point screws secure joint shafts, linear guides, and drive components, enhancing motion accuracy.

Automation Equipment: Key parts in packaging machinery, assembly robots, or conveyor systems rely on cone point screws to ensure efficient, long-term operation.
